Wet Blast Cabinet BW900WB
Manufactured in Northamptonshire, our Blast Wash Wet Blast Cabinets are amazing surface finishing machines designed for blast washing small to medium components. By blast washing with media through the flow of the water, it leaves a smooth, silky finish to the components.
Our Wet Blast Cabinets function using a mixture of abrasive media and water contained in the slurry pump system. Compressed air is then introduced to propel the abrasive media and water mixture onto the surface of the component, instantly creating a clean and soft finish.
From £9,495 +VAT
Enquire About This ProductCall Us: +44 (0) 1604 811505
Product Features
- UK designed and manufactured
- Optional closed/open loop system, blast gun holder, rubber lining, bogey & trolley loading turntable
- Compatible with a range of media (depending on application)
- Heavy duty 2.2KW pump motor capacity
- Choice of nozzle size with a stainless steel air jet
- Water rinse gun
- 24V windscreen wiper motor
- Adjustable pressure control
- 12 months UK warranty
- Able to remove surface carbon, mud, paint, resin, oil, lacquer, primer, ink, rust, plating, lime scale, adhesives and more
Enquire About This ProductCall Us: +44 (0) 1604 811505
Blast-Wash Suppliers Of New And Used Machinery
Product Specifications
All three sizes of the Blast Wash Wet Blast Cabinet are manufactured from a fully stainless steel material and perfected with a durable white powder coating finish. Each cabinet features a large right door opening as standard to seamlessly insert and remove components, however, door placement can be modified upon request.
All of the Wet Blast Cabinets can safely hold up to 150kg of components for processing as standard. Heavier weight loads can be accommodated if necessary.
Size Specifications
Model
Height
Depth
Width
BW900WB External
1924mm
1448mm
988mm
BW900WB Internal
945mm
1070mm
900mm
Enquire About This ProductCall Us: +44 (0) 1604 811505
Installation Requirements
Power – 3 Phase – 32amp C type 3ph N+E supply with a trailing lead and 5 pin plug or Single Phase – 240v socket with plug and trailing lead (chargeable option)
Air – You will require a ½” BSP Ball Valve for the air supply along with, a minimum of 35-40 CFM
Waste Drain – Close by to the machine you will need a waste drain for the outlet, unless you have a closed loop system.
Water – You require a ½” BSP Ball Valve or Standard Water Tap, which reaches the machine unless you have a closed loop system.
Other – The machine will need to be positioned on a suitable floor space, which must be level. You will also require a forklift or other means to offload onsite.
